X-SENSORS Strain Sensor X-103 Series Introduction

characteristic

Very flat design, only 6.5 mm high

Strain sensor with mV / V output (strain gauge measuring bridge)

For static and dynamic applications

For force, weight and deformation measurements

Measuring very small strains in rigid structures

Surface strain sensor X-103 monitors strain between two mounting screws and mechanically amplifies it. In this way, the strain is concentrated in the measurement area, so that it can be measured using a resistance strain gauge bridge.

If strain gauges are used to measure the mV / V signal of the bridge or multiple strain sensors should be connected, these strain sensors should be used. This is the case for weight measurement and force measurement on several tension rods of the press. The strain sensor will generate a proportional strain bridge signal (mV / V) based on the stress of the structure.

Extremely robust steel housing, combined with IP65 protection, ensures trouble-free operation even under harsh and harsh environmental conditions

use

This strain sensor is suitable for static and dynamic applications:

Force measurement in machinery (e.g. presses, welding tongs, assembly machines)

Force measurement in presses and injection molding machines

Weight is determined by measuring the deformation of the load-bearing structure. This is a cost-effective way to retrofit existing structures (e.g. silos) by weight measurement.

Monitoring mechanical deformation of components

Monitoring of buildings and building loads to avoid severe overloading

X-SENSORS Strain Sensor X-103 SeriesModel

X-SENSORS X-103-D22

X-SENSORS X-103-S10

X-SENSORS X-103-S15

X-SENSORS X-103-S30
